Operator Environment
The Spirit Delta cab gives the operator a safe and efficient place to work from. The cab design is the end result of a major analysis of operators' working conditions. The main objective is to provide optimum visibility with no forward corner posts and big glass areas unobstructed to keep the field of vision clear. The instrumental panel is ergonomically designed and is extremely comfortable and gently rounded. This area has also been designed with an unobstructed clear view of all essential info, in order to keep the operator functioning as effectively as she or he could.
Due to the insulated mounting to the chassis, overall noise levels and vibration levels are kept low. The controller's seat and the hydraulic controls are all independently adjustable that allows you to maintain an optimum working position. Additionally, the steering wheel and related panel is adjustable for utmost comfort. There are 2 ergonomically positioned multi-functioned and simple to operate levers which are offered for the horn, window washers, gear changing and windscreen wipers.
To guarantee a comfortable cab temperature for the operator, a ventilation/heating unit supplies incoming air that is replaced by an air filter. This is easily replaceable and the unit slides out afterwards to make serviceability an easy option. The machinery has a robust 3-speed fan for recirculation, defrosting, cooling and heating. As an extra option, air conditioning can be fitted.
Instrumentation
The instrument panel in the spirit delta cab has been logically grouped and are all accessible. The standard instruments which include: low brake pressure, high coolant temperature, warning lamps, low engine and gearbox lubrication oil pressure, high gearbox oil temperature and applied parking brake. In addition, gauges display values for fuel quantity, operating time, engine coolant and gearbox oil pressure.
Amongst the key options the 8 to 10 tonne trucks could be equipped with is the ECS or Electronic Control System monitoring. This allows for easy supervision of the unit. All of the monitoring functions are handled by the ECS and incorporated by this system. The full text display and the single warning lamp show any faults which happen and their current values.
